1. Possible Work-Piece Length:
With One Vice Min.
With Two Vices Min.
With One Vices Max.
|
- |
40mm
110mm
500/1000/1500/2000mm |
2. Min. Work-Piece dia. admitted in vices
|
- |
12mm |
3. Max. Work-Piece dia. admitted in vices
|
- |
125mm |
4. Clamping System
|
- |
Hydraulic Motor |
5. Spindle Speeds
|
- |
350/500/750/1000 RPM |
6. Max. Stroke of each Quill
|
- |
50mm |
|
7. Quill Feed (infinitely variable)
|
- |
Hydraulic |
8. Max. Plunge Facing Diameter
|
- |
63mm |
9. Center Drill Sizes
|
- |
BSS3 to BSS6 or equivalent as per ISI |
9. Center Drill Sizes
|
- |
BSS3 to BSS6 or equivalent as per ISI |
10. Motor Power:
Spindle Motor(each)
Hydraulic Power Pack
Coolant Motor
Total Power
|
- |
2.2 kw / 960RPM
3 kw / 1440 RPM
0.1 kw / 2800 RPM
7.5 kw |
|
